S203
Installation Audio Cable S203
PVC Ø6.0m - 2x0.30 mm²
Part. No.: 24-0304
| General | |
| Part number : | 24-0304 |
| Cable model : | S203 |
| Cable type : | Audio Cable |
| Properties : | Analog |
| Conductor material : | OFC |
| Application area : | Stage / live |
| Application type : | Installation / indoor |
| Application of voltage : | Low voltage |
| Construction | |
| Jacket material : | PVC |
| Colour : | black |
| Jacket shape : | round |
| Jacket diameter [mm] : | 6 |
| Conductor : | 2 × 0.30 mm² |
| AWG : | 22 |
| Copper construction mm : | 38 × Ø 0.10 |
| Weight kg/roll： | 10.64kg |
| Packing m/roll ： | 200 |
| Min. bending radius : | 30 |
| Min. temperature [°C] : | -20 |
| Max. temperature [°C] : | 70 |
| Electrical Data | |
| Capacitance pF/m | 61 |
| Conductor resistance Ω/km | <52 |
| Max. operating voltage V | 300 |
