DC108B
Digital Cable
PVC Ø7 mm - 1x0.5 mm²
Part. No.: BC0024
| General | |
| Part number : | BC0024 |
| Cable model: | DC108B |
| Cable type; | Coaxial Cable |
| Properties: | Digital |
| Conductor material: | OFC |
| Application area: | SDI/video |
| Application type: | Indoor |
| Application of voltage: | Low voltage |
| Standards: | CE/Rosh |
| Construction | |
| Jacket material : | PVC |
| Colour | black |
| Jacket shape; | round |
| Jacket diameter [mm]: | 6.5 |
| Conductor ; | 1 × 0.5 mm² |
| AWG: | 20 |
| Copper construction mm: | 1 × Ø 0.8 |
| Insulation material : | Foam/skin-PE |
| Conductor shielding: | Tined copper braided + PT AL foi |
| Weight kg/roll： | 9.5kg |
| Packing m/roll ： | 200 m |
| Min.bending radius | 33 |
| Min.temperature [C]: | -20 |
| Max.temperature [C]: | 70 |
| Electrical Data | |
| Capacitance pF/m | 55 |
| Conductor resistance Ω/km | <36 |
| Max.operating voltage V | 300 |
